24ft x 9ft Steel Anti – Vandal Office Cabin | Portable Site Office UK

24ft Anti Vandal Office Cabin | Portable Site Office UK

The 24ft x 9ft Steel Anti – Vandal Office Cabin is designed to provide safe, comfortable, and highly secure administrative space on demanding construction sites, industrial yards, and temporary commercial developments. Offering an efficient 200 sq ft internal footprint, this anti – vandal office unit eliminates security risks while providing a modern, climate – controlled working environment.

Built from heavy – duty corrugated steel panels, each cabin features fully welded exterior seams to resist forced entry, extreme UK weather, and long – term site wear – and – tear.

Key Structural & Security Features

1. Maximum Anti – Vandal Security Protection

• Steel Window Shutters: Fitted with dual sliding windows protected externally by heavy – gauge steel anti – vandal shutters with internal shoot – bolt locks.

• 10 – Point Locking Personnel Door: High – security steel door with anti – jemmy frames and a multi – point locking system to safeguard expensive site equipment, IT hardware, and project files.

2. Fully Finished Climate – Controlled Interior

• Thermal Insulation: Walls, roof, and floor are fully insulated with 50mm thermal insulation to maintain a warm interior in winter and prevent summer heat buildup.

• Integrated Electrics & Heating: Pre – wired to UK standards with a 32A external Commando inlet, consumer unit, bright LED lighting, double power sockets, and a 2kW electric convector heater.

3. Low – Maintenance, Durable Materials

• Commercial Vinyl Flooring: Heavy – duty, seamless vinyl floor covering designed to withstand heavy work – boot traffic, mud, and frequent cleaning.

• Wipe – Clean Wall Boarding: Internal wall lining made from durable composite boards that wipe down effortlessly to maintain a clean workspace.

Technical & Dimensional Specifications

Providing complete structural and electrical data directly addresses technical site requirements, builds buyer confidence, and positions the page for Google rich snippet placements.

Feature / Specification	External Dimensions	Internal Cavity Dimensions	Window & Door Specs
Length	24 ft 0 in (7.31 m)	23 ft 3 in (7.08 m)	Doors: 10 – point locking anti – vandal steel door
Width	9 ft 0 in (2.74 m)	8 ft 3 in (2.51 m)	Windows: 2x sliding aluminum windows with steel anti – vandal shutters
Height	8 ft 6 in (2.59 m)	7 ft 6 in (2.28 m)	Wall Insulation: 50mm high – density thermal insulation
Tare Weight (Approx.)	~3,800 kg – 4,200 kg	–	–
Electrical Package	32A External CEE Hookup, Consumer Unit, 2x LED Batten Lights, 4x Double Sockets	–	–
Heating	2kW thermostatically controlled electric wall heater	–	–
Flooring	Heavy – duty 18mm plywood overlay with commercial non – slip vinyl sheet	–	–
Wall & Ceiling Lining	Washable, fire – retardant wipe – clean composite wall boards	–	–

Delivery, Site Setup & Crane Requirements

Positioning a 24ft x 9ft office cabin requires standard site access planning:

1. Delivery Vehicle: Transported via a 6 – wheel or 8 – wheel HIAB crane lorry for precise offloading onto your prepared pad or hardstanding area.

2. Access Clearance: Requires a minimum of 50 ft (15.2 m) straight – line access for lorry maneuvering and crane arm extension.

3. Foundation Requirements: Must be positioned on a solid, level surface (concrete pads, compacted hardstanding, or heavy timber sleepers) to keep doors and window shutters square.
